Model # DTP-4012V
The fuel DC pump is equipped with the suction pipe, delivery hose, and nozzle that are fixed, and installed internally in the case. For more convenient operation, the pump and fittings are connected by a rotating swivel connector.
PUMP:
- Self-priming, volumetric, rotating vane pump, equipped with by-pass valve. With the 3/4’’ rotating swivel connector.
MOTOR:
- Brush motor, DC, low tension with intermittent cycle, closed type in protection class IP55, directly flanged to the pump body.
SUCTION TUBING:
- Minimum recommended nominal diameter: 3/4”
- Nominal recommended pressure: 10bar/145PSI
- Use tubing suitable for functioning under suction pressure
DELIVERY TUBING:
- Minimum recommended nominal diameter: 3/4”
- Nominal recommended pressure: 10bar/145PSI
NOZZLE:
- Aluminum Manual nozzle
- Connection: 3/4’’
BOX: The case is made from high-density polyethylene material.
